DLS Flatbox D-One

- Type: 2-way bass reflex

- Woofer: 1 x 5,5"

- Tweeter: 30 mm

- Impedance: 4 ohm,

- Sensitivity: 89 dB/1m, 1W

- Recommended amplifier: 30 - 150 Watts,

- Frequency resp.:  62 - 25 000 Hz

- Dimensions H x W x D: 360 x 360 x 115 mm,

- Weight: 5,5 kg per speaker

DLS Flatbox Midi

- Type:    2-way bass reflex

- Woofer / woofer midrange: 1x4" paper cone,

- Tweeter:   30 mm soft dome

- Impedance:    8 ohm,

- Sensitivity:   88 dB/1m, 1W

- Recommended amplifier:  30 - 150 Watts,

- Frequency response:  65 - 25 000 Hz

- Dimensions H x W x D:  380 x 210 x 92 mm

- Weight:   4 kg per speaker

DLS Flatbox Slim Large

- Type: 2-way bass reflex

- Woofer: 1x3” ,

- Tweeter: 22 mm soft dome

- Impedance: 8 ohm,

- Sensitivity: 86 dB/1m, 1W

- Recommended amplifier: 30 - 120 Watts,

- Frequency resp.:  70 - 25 000 Hz

- Dimensions H x W x D: 470 x 170 x 80 mm,

- Weight: 2,83 kg per speaker

DLS Flatbox Slim XL

- type 2-way bass reflex for wall mount

- Finish / colour Black piano finish, white and black front grill included

- Impedance 4 ohm

- Woofer size 2 x 4” + 2 x 4” slaves

- Tweeter 30 mm soft dome

- Frequency range 65 - 25 000 Hz

- Sensitivity 89 dB / 1W, 1m

- Recommended amplifier 30 - 150 Watt, 4 - 8 ohm

- Dimension (W x D x H) 145 x 92 x 1100 mm

- Weight 6,9 kg

DLS Flatbox XL

- Type:    2-way bass reflex

- Woofer / woofer midrange: 2x4”,

- Tweeter:   30 mm soft dome

- Impedance:    4 ohm, - Sensitivity:   89 dB/1m, 1W

- Recommended amplifier:  30 - 150 Watts,

- Frequency response:  65 - 25 000 Hz

- Dimensions H x W x D:  220 x 630 x 92 mm

- Weight:   5,9 kg per speaker

DLS Flatbox XXL

- Type:    2.5-way bass reflex

- Woofer: 1 x 4" / woofer midrange: 2 x 4”,

- Tweeter:   30 mm soft dome

- Impedance:    4 ohm, - Sensitivity:   90 dB/1m, 1W

- Recommended amplifier:  30 - 200 Watts,

- Frequency response:  58 - 25 000 Hz

- Dimensions H x W x D:  940 x 240 x 92 mm

- Weight:   11,1 kg per speaker

DLS Flatbox M-One

- Type: 2-way bass reflex

- Tweeter: 30 mm Waveguide

- Impedance: 4 ohm,

- Sensitivity: 91 dB/1m, 1W

- Recommended amplifier: 50 - 150 Watts,

- Frequency resp.:  45 - 30 000 Hz

- Dimensions H x W x D: 600 x 280 x 111 mm,

- Weight: 8,5 kg per speaker

DLS Flatbox M-Two

- Type: 2.5-way bass reflex

- Woofer: 1 x 6,5” aluminum cone

- Woofer / Mid: 1 x 6,5" kevlar cone

- Tweeter: 30 mm Waveguide

- Impedance: 4 ohm,

- Sensitivity: 92 dB/1m, 1W

- Recommended amplifier: 50 - 250 Watts,

- Frequency resp.:  40 - 30 000 Hz

- Dimensions H x W x D: 1050 x 320 x 111 mm,

- Weight: 16,9 kg per speaker

DLS Flatsub Midi

No cloth fronts, subwoofer on back side. Wall bracket included.

- Type:    8” subwoofer in vented box

- Amplifier power:    150 Watts class D

- Low pass filter  40 - 200 Hz variable, - High pass filter  25 Hz fixed

- Phase control  0-180 degrees continuously

- Frequency response:  25-200 Hz

- Power input:  230 / 115 V AC

- Dimensions: H x W x D:  400 x 445 x 172 mm

DLS Flatsub 8.2

Both black and white grille included. Wall bracket included.

- Type:    8” subwoofer in closed box

- Output power:    250 Watts

- Low pass filter  40 - 200 Hz variable, - High pass filter  25 Hz fixed

- Phase control  0-180 degrees continuously

- Frequency response:  25-200 Hz

- Power input:  230 / 115 V AC

- Dimensions: H x W x D:  300 x 465 x 171 mm

DLS Flatsub 8 Large

Both black and white grille included. Wall bracket included.

- Type:    8” subwoofer in closed box

- Output power:    150 Watts

- Low pass filter  40 - 150 Hz variable, - High pass filter  25 Hz fixed

- Phase control  0-180 degrees continuously

- Frequency response:  30-150 Hz

- Power input:  230 / 115 V AC

- Dimensions: H x W x D:  340 x 670 x 155 mm

DLS Flatsub Stereo One

Both black and white grille included. Wall bracket included.

- Type:    Active subwoofer with built in stereo amplifier

- Woofer:   7" + passive radiator 7"

- Output power:    80 W for sub, 2 x 35 W for stereo, Class D

- Low pass filter  50 - 250 Hz variable

- Bass EQ  + 5 dB @ 35 Hz

- Bluetooth receiver for wireless streaming is included

- Power input:  230 / 115 V AC

- Dimensions: H x W x D:  300 x 550 x 165 mm
